| Brand | Whirlpool |
| Model # | WEG745H0FH |
| Width | 29.88 in. |
| Height | 36 in. |
| Depth | 28.88 in. |
$0.00
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Lowest Price Guarantee
Need help? (732) 426-0990
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width29.88 in.
Height36 in.
Length28.88 in.
Weight204 lbs.
Depth Closed Excluding Handles28-7/8 in
Depth With Door Open 90 Degree48-3/4 in
Gross Weight204 lbs
Oven Interior Depth20-5/8 in
Oven Interior Height22-1/8 in
Oven Interior Width24-1/8 in
Certifications
ADA CompliantADA Height and Operation Compliant
Prop 65Standard
UlYes
Exterior Details
Door TypeMetal & Glass
Handle ColorStainless Steel
Handle MaterialMetal
Knob ColorColor Coordinated/Black on Stainless
Knob TypeWeighted
Oven Control LocationFront
Oven Control TypeElectronic Touch
Oven Window SizeExtra Large
Element/burner Details
Center Front Element-burner TypeSealed Burner
Center Rear Element-burner Power8,000 BTU
Cooktop Element StyleGas Burner
Left Front Element-burner Power17,000 BTU
Left Front Element-burner TypeSealed Burner
Left Rear Element-burner Power5,000 BTU
Left Rear Element-burner TypeSealed Burner
Number Of Cooking Element-burners5
Number Of Grates2
Right Front Element-burner Power15,000 BTU
Right Front Element-burner TypeSealed Burner
Right Rear Element-burner Power9,200 BTU
Right Rear Element-burner TypeSealed Burner
Cooktop Details
Auto Re-ignitionNo
Cooktop Control LocationFront
Cooktop Control TypeKnobs
Cooktop Surface ColorWhite
Cooktop Surface MaterialPorcelain Coated Steel
Heating Element On Indicator LightNo
Hot Surface Indicator LightNo
Ignition TypeElectronic
Oven Cavity Details
Automatic Convection Conversion Temperature AdjustYes
Bake Element Power18,000 BTU
Broiler Element Power13,000 BTU
Broiler LocationTop of Oven
Convection Element TypeFan
Convection FunctionsBake, Broil, Roast
Hidden Bake ElementYes
Interior ColorGrey
Number Of Oven Lights1
Number Of Oven Racks3
Number Of Rack Guides7
Oven Cleaning TypeAquaLift® Steam Clean
Oven Cooking SystemConvection
Oven Light TypeIncandescent
Oven Rack Type2 Standard and 1 Max Capacity
Details
Fuel TypeGas
Oven ConfigurationSingle Oven
Oven SelectionsControl Lock, Convect Modes, Cook Time Indicator, Delay Start, Frozen Bake, Keep Warm Setting, Rapid Preheat, Sabbath Mode, Settings
Power On Indicator LightYes
Power Outage CompatibleNo
Range ConfigurationSlide-In
Range TypeSlide-in
Controls
Display ColorBlue
Electronic Display TypeDigital
Grate Details
Grate DetailsCast Iron Grates, Dishwasher Safe, Matte Finish, Rear Hinged Grate
Number Of Grates2
Electrical
Amps15
Power Cord IncludedYes
Volts120
Refinements
FeaturesADA Compliant, EZ-2-Lift™ Hinged Grates, Frozen Bake™ Technology, Sabbath Mode/Star-K Certification, Self-Cleaning, True Convection, Bladed Knob, Whirlpool Handle
Other
Capacity5.8 cu. ft.
Common Size30 in
