| Brand | Cafe |
| Model # | CDB36LP2RS1 |
| Width | 36 in. |
| Height | 84 in. |
| Depth | 28.5 in. |
$8,499.00
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Net Weight610 lb
Case Depth Without Door23.625 in
Depth Without Handle25.3125 in
Height To Top Of Case83.5 in
Overall Height84 in
Height To Top Of Hinge84 in
Overall Width36 in
Overall Depth28 1/2 in
Width36 in.
Height84 in.
Length28.5 in.
Weight610 lbs.
Warranty
Parts1 Year
Labor1 Year
Warranty NotesSee written warranty for full details
Parts WarrantyLimited 1-year entire appliance
Labor WarrantyLimited 1-year entire appliance
Features
Communication ModuleRequired
Filter LocationBehind the top access panel
Refrigerant TypeR-134a
Freezer FeaturesFreezer Drawer with Full Extension Slides
Filter Change IndicatorYes - On Upfront Control
ConfigurationBottom Freezer
Deli DrawerSealed
WiFi ConnectOptional (Requires part no. PBX23W00Y1)
Leveling System4 Point (2 adjustable back rollers, 2 adjustable front legs)
Fresh Food Door Features2 with Gallon Storage
Fresh Food Door Bins4
Vegetable / Fruit Crisper(s)2 Drawers w/ Full-Extension Slides
Exterior StyleBuilt-In
Snack Drawer2 Snack Drawers w/ Full-Extension Slides
Water FiltrationGE Water Filtration 6 Month
Freezer Storage Baskets2 Wire
Product TypeBottom Freezer Refrigerator
Defrost TypeAutomatic Defrost
Temperature Management FeaturesIndependent Temperature Controls
DispenserNon-Dispenser
Produce DrawerSealed Adj. Humidity
Freezer Cabinet Shelves1 Freezer Drawer/Ice Bucket on Full-Extension Slides
Independent Utility Basketwith Full Extension Slides
Fresh Food Cabinet Shelves5
IcemakerFactory-Installed
Fresh Food FeaturesDairy Compartment - 2
Sabbath ModeYes
Interior LightingLED
Control TypeUpfront Electronic Digital Temperature Display
Ou CertifiedNo
Fresh Food Cabinet Shelf Features1 Fixed
Appearance
HandleCafé™
InstallationIndustry Standard Built-In Installation
Door Stops90, 115 and 130 Degree
Master Light Control SwitchYes
Wrapped Stainless Steel Door And GrillYes
Adjustable Rollers2
Easy Access Hinged GrilleYes
Handle ColorBrushed Stainless
Coil-free BackYes
Hidden Door Hinge(s)Yes
Door StyleSolid Door
Color AppearanceStainless Steel
Door SwingHinges on Left
Accessories
Optional KitsCXSB2H2PPBT - Brushed Black
Capacity
Fresh Food Capacity14.95 cu ft
Freezer Capacity6.32 cu ft
Economical / Quiet
Quiet FeaturesStainless Sealed Adjustable Toe Kick
Power & Ratings
Volts/hertz/amps115V; 60Hz; 20A
