| Brand | Fisher Paykel |
| Model # | RDV3485GDN |
| Width | 47 in. |
| Height | 35 in. |
| Depth | 29 in. |
$0.00
Ships When Available— Backorder OK
Rebate Available
Mail-in rebate savings
Fisher And Paykel 15% And Warranty Extension Rebate
TieredUP TO 15% REBATE & WARRANTY EXTENSION
ManufacturerMail-InJan 1 – Dec 31, 2026
Open form to see all rebate tiersRebates applied via mail-in forms. Call (732) 426-0990 with questions.
This item is on backorder and will ship when available.
Lowest Price Guarantee
Need help? (732) 426-0990
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width47 in.
Height35 in.
Length29 in.
Other
Supply Pressure (lpg)11" to 14" W.C
Capacity Total (aham)2.1 cu ft
Capacity Usable (aham)1.8 cu ft
Full Extension Telescopic Racks2
Shelf Positions5
Number Of Main Oven Functions15
Main Oven - Bake Power4600W
Main Oven - Broil Power4000W
Secondary Oven - Bake Power2450W
Secondary Oven - Broil Power3600W
Amperage50A
Supply Frequency60Hz
Supply Voltage120 - 240V
Simmer On All Burners140°F
Max Burner Power19,000 BTU
Parts And Labor2 years
Accessories (included)
GeneralYes
Adjustable Feet CoversYes
Branded Coin End CapYes
Burner Ratings
GeneralYes
Maximum Burner Power23500 BTU
Power Back Centre23500BTU
Power Back Left18500BTU
Power Back Right18500BTU
Power Front Left18500BTU
Power Front Right18500BTU
Power Griddle24000BTU
Total Cooktop Power121500 BTU
Capacity
GeneralYes
Shelf Positions (main Oven)5
Shelf Positions (second Oven)5
Total Capacity (main Oven)4.8cu ft
Total Capacity Second Oven2.1cu ft
Usable Capacity (main Oven)3.8cu ft
Cleaning
GeneralYes
Easy Clean Porcelain BasepanYes
Pyrolytic Self-cleanYes
Controls
GeneralYes
Dial With Illuminated HaloYes
Dual Control Oven DialsYes
Electric Circuit4 wire
High Resolution DisplayYes
Metal Illuminated DialsYes
Multi-language InterfaceYes
Precise Cooking With Food ProbeYes
Recipe And Food Based FunctionsYes
Sabbath ModeYes
Smart ApplianceYes
Tilting Touch Screen InterfaceYes
Wi-Fi ConnectivityYes
Gas Requirements
GeneralYes
Fitting And Pipe½ NPT, min. ⅝" ∅ flex line
Supply Pressure (natural Gas)6" to 9" W.C
Oven Features
GeneralYes
Auto Re-ignition SystemYes
Concealed ElementYes
Electronic Oven ControlYes
Full Extension Telescopic Sliding ShelvesYes
Titanium Coated, Illuminated Metal DialsYes
Oven Functions
GeneralYes
Air FryYes
BakeYes
Classic BakeYes
CleanYes
Convection BakeYes
Convection BroilYes
Maxi BroilYes
Number Of Functions15
Pastry BakeYes
Pizza BakeYes
Rapid ProofYes
RoastYes
Slow CookYes
True ConvectionYes
WarmYes
Oven Performance
GeneralYes
Bake Power4600
Broil3600W
Main Oven - True Convection Power2500W
Power Requirements
GeneralYes
Connection4-prong grounding type [NEMA 14-50 plug]
Power Supply120 / 240 V, 60 Hz
Service50 A
Rangetop Features
GeneralYes
Sealed Range TopYes
Vent Trim IncludedYes
Recommended Back Guards Ventilation
GeneralYes
Combustible SituationBGRV3-3048H
Non Combustible SituationBGRV2-3048 / BGRV2-1248
Recommended HoodHCB48-12_N (48"" Professional Range Hood, Dual Blower)
Safety
GeneralYes
ADA CompliantYes
Secondary Oven Features
GeneralYes
3/4 Extension Racks2
Concealed ElementYes
Electronic Oven ControlYes
Food ProbeYes
Internal LightYes
Secondary Oven Functions
GeneralYes
Air FryYes
BakeYes
Classic BakeYes
Convection BakeYes
Convection BroilYes
Maxi BroilYes
Number Of Secondary Oven Functions11
Pastry BakeYes
Pizza BakeYes
Rapid ProofYes
RoastYes
WarmYes
