| Brand | GE |
| Model # | JGBP86DEMWW |
| Width | 30 in. |
| Height | 47 in. |
| Depth | 26.25 in. |
$1,149.00
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Overall Width30 in
Overall Height47 in
Net Weight200 lb
Oven Interior Dimensions (w X H X D) (in.)24 x 19 x 19
Depth With Door Open 90°46.375 in
Cabinet Width30 in
Overall Depth26 1/4 in
Height To Cooking Surface (in.)36.25 +/- .25
Width30 in.
Height47 in.
Length26.25 in.
Weight200 lbs.
Features
ConfigurationRange with Storage Drawer
Cleaning TimeVariable
Ignition SystemElectronic
Interior Oven LightYes
Fuel TypeNatural Gas
Cooktop Burner TypeSealed
Oven Rack Features2 Oven Racks
Power Boil Burner(1) 17,000 BTU
Temperature Management SystemTrue Temp System
Oven Cleaning TypeSelf-Clean
High Output Burner(1) 11,000 BTU/150F degree simmer
All-purpose Burners(1) 9,100 BTU/150F degree simmer
Cooktop Burner Grate MaterialHeavy Cast
Valves (degree Of Turn)270
Cooktop Burner Grate FeaturesContinuous Grates
BackguardPorcelain-Enameled
Center Oval Burner(1) 6,000 BTU
Cooktop SurfaceOne-Piece Upswept
Oven Rack Positions (single Or Upper/lower)6
Leveling System4 Leveling Legs
Precise Simmer Burner(1) 5,000 BTU/140F degree simmer
Self-clean Oven Door LockManual
Cooking TechnologyTraditional
Control TypeDigital Temperature Display
Oven Control FeaturesIn-Oven Broiling
Appearance
Cooktop Burner Grate ColorGray
Oven Door FeaturesBig Hearth Oven Window
HandleColor-Matched Sculptured
Frameless Oven Door(s)White Glass
Control KnobsDesigner-Style
Color AppearanceWhite on White
Capacity
Unit CapacityExtra Large Oven
Accessories
LP Conversion KitIncluded
Power & Ratings
Top Burner BTU Rating - Nat. Gas (000's BTU's)(1) 16.0; (1) 11.0; (1) 9.1; (1) 6.0; (1) 5.0
Volts/hertz/amps120V; 60Hz; 5A
Top Burner BTU Rating - LP (000's BTU's)(2) 11.0; (1) 9.1; (1) 6.0; (1) 5.0
Bake/broiler BTU Rating - Nat. Gas (000's BTU's)16.0 Bake / 13.5 Broiler
Bake/broiler BTU Rating - LP (000's BTU's)16.0 Bake / 12.0 Broiler
Warranty
Labor WarrantyLimited 1-year entire appliance
Parts WarrantyLimited 1-year entire appliance
Warranty NotesFor models produced on or after January 1, 2006
