| Brand | Thermador |
| Model # | DWHD770WPR |
| Width | 23.56 in. |
| Height | 33.88 in. |
| Depth | 23.06 in. |
$2,549.00
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width23.56 in.
Height33.88 in.
Length23.06 in.
Weight101 lbs.
Net Weight101.000 lbs
Weight Furniture Front (min - Max)3 - 10 kg
Length Outlet Hose (in)90 1/2''
Power Cord Length67''
Product Packaging Dimensions (hxwxd)35 3/4'' x 26'' x 29 5/16''
Connectivity
Home Connect® WiFi-enabledyes
Home Connect® FeaturesRemote Monitoring and Control
Power Consumption Standby/network: Please Check The User Manual For How To Switch Off The WiFi Module.2.0 W
Time Auto-standby/network2.0 min
Programs
Status IndicatorEnd of program audible, Rem. time proj. white, Sanitized LED US, Water inlet
List Of Programs1 Hour, Auto, Hand Wash, Normal, Pots & Pans, Quick, Rinse
Program 1Pots & Pans
Program 2Auto
Program 3Normal
Program 4Hand Wash
Program 51 Hour
Program 6Quick
Program 7Rinse
Reference ProgramRegular US
Temperature Program 1150-160 °F
Temperature Program 2130-150 °F
Temperature Program 3122-131 °F
Safety
ChildlockYes
SafetyPush Two Times to Open, 24/7 AquaStop® Leak Protection
Consumption Values
Crystal Protect®Yes
Water Consumption Program 14.8-6.3 gal
Water Consumption Program 23.5-6.6 gal
Water Consumption Program 31.5-4.5 gal
Water Consumption Program 71 gal
Total Annual Water Consumption624 gal
Maximum Temperature For Water Intake (°c)60 °C
Connection
Watts1,440 W
Power Cord Length67''
Amps12 A
Plug TypeNema5-15P
Comfort And Convenience
3rd RackAdjustable Chef’s Tool Drawer®
Adjustable Upper Rackyes
Time Remaining Powerbeam®yes
Program Status LightNot Applicable
Sapphire Glow™yes
Multi-color Star Glowno
Crystal Protect®yes
Open Door Assistyes
Cleaning Technology
Drying SystemStarDry™ with Zeolite, Condensation Dry
Nsf® Certified Sanitize Optionyes
Cycle OptionsRemote Start, PowerBoost®, Save Time, Half Load, Sanitation, StarDry™
List Of Programs1 Hour, Auto, Hand Wash, Pots & Pans, Quick, Normal, Rinse
Aquasensoryes
Water Softeneryes
Energy And Water
Energy Star® Certifiedyes
Total Annual Energy Consumption269 kWh
Total Annual Water Consumption624 gal
