| Brand | Thor Kitchen |
| Model # | LRG3601U |
| Width | 36 in. |
| Height | 36.31 in. |
| Depth | 28.31 in. |
$3,144.00
$4,849.00Save $1,705.00 (35%)
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width36 in.
Height36.31 in.
Length28.31 in.
Net Weight215 lbs.
Gross Weight288 lbs.
Product Height (from Bottom To Top Of Side Panel)35 5/8 inch-36 5/8 inch
Product Depth (from Back Panel To Control Board)27 1/16 inch
Product Depth (from Back Panel To Side Panel Front)24 3/4 inch
Depth Of Control Panel (minimum)2 1/4 inch
Depth Of Control Panel (bullnose)3 9/16 inch
Product Width36"
Product Height (from Bottom To Top Of Back Splash)36 5/8”-37 5/8”
Product Depth (from Back Panel To Bullnose)27 1/2”
Adjustable Legs1" Max.
Technical Details
Fuel TypeNatural Gas / LP Convertible
Installation TypeFreestanding
ColorStainless Steel
Electrical Requirements120V
Frequency (hz)60 Hz
Controls TypeKnob
Circuit Breaker (a)15A
Burner Performance
Total Burners6
[1] Front Left (single)18,000 BTU
[2] Front Middle (single)12,000 BTU
[3] Front Right (single)18,000 BTU
[4] Rear Left (single)9,000 BTU
[5] Rear Middle (single)12,000 BTU
[6] Rear Right (single)9,000 BTU
Tube Broil Burner10,000 BTU
Bake Burner (30” Oven)18,500 BTU
Other
Adjustable Leg Sizes1 in. Max.
