| Brand | Thor Kitchen |
| Model # | HRD4803ULP |
| Width | 47.9 in. |
| Height | 57.5 in. |
| Depth | 27.88 in. |
$8,499.00
$11,049.00Save $2,550.00 (23%)
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width47.9 in.
Height57.5 in.
Length27.88 in.
Product Height (from Bottom To Top Of Side Panel)35 15/16" – 36 15/16"
Product Depth (from Back Panel To Control Board)26 1/2"
Product Depth (from Back Panel To Side Panel Front)24 3/16"
Depth Of Control Panel (minimum)2 1/4"
Depth Of Control Panel (bullnose)3 11/16"
Product Width47 7/8"
Product Height (from Bottom To Top Of Back Splash)38 1/2”-39 1/2”
Product Depth (from Back Panel To Bullnose)27 7/8”
Cast Iron Cooking Grate (w X L)10 3/4” x 21 1/2”
Adjustable Leg Sizes1" Max.
Technical Details
Fuel TypeLiquid Propane Ready
Installation TypeFreestanding
ColorStainless Steel
Electrical Requirements240V, 4-Prong 14-50R Power Outlet
Frequency (hz)60 Hz
Controls TypeKnob
Circuit Breaker (a)20A
Burner Performance
Total Burners6
(1) Front Left (single)18,000 BTU
(2) Front Middle (dual Burner)15,000 BTU (650 BTU for Simmer)
(3) Front Right (single)18,000 BTU
(4) Rear Left (single)12,000 BTU
(5) Rear Middle (single)12,000 BTU
(6) Rear Right (dual Burner With Simmer Function)15,000 BTU (650 BTU for Simmer)
(7) Stainless Steel Griddle15,000 BTU
Oven Performance
Oven Capacity6.7 cu. ft. (4.2 cu. ft. for 30-inch oven) (2.5 cu. ft. for 18-inch oven)
Bake Power (18-inch Oven)2,500 W (Bottom)
Bake Power (30-inch Oven)3,000 W
Broil Power (30-inch Oven)850 W + 3,000 W
Weight
Net Weight395 lbs.
Gross Weight527 lbs.
