| Brand | Whirlpool |
| Model # | WFG745H0FE |
| Width | 29.88 in. |
| Height | 46.88 in. |
| Depth | 27.88 in. |
$1,149.00
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width29.88 in.
Height46.88 in.
Length27.88 in.
Weight187 lbs.
Cutout Height36 in
Cutout Width30 in
Gross Weight187 lbs
Oven Interior Height20 in
Depth Closed Excluding Handles25.438 in
Depth With Door Open 90 Degree47.938 in
Maximum Height47.875 in
Minimum Height46.875 in
Oven Interior Depth20.75 in
Oven Interior Width24.375 in
Net Weight187 lbs
Exterior Details
Door TypeMetal & Glass
Handle ColorStainless Steel
Handle MaterialMetal
Handle TypeReach Through Handle
Knob ColorColor Coordinated
Knob TypeDishwasher-Safe Weighted
Oven Window SizeLarge
Oven Control TypeElectronic Touch
Oven Control LocationBackguard
Oven Cavity Details
Automatic Convection Conversion Temperature AdjustYes
Broiler LocationTop of Oven
Convection Element Power925 w
Convection Element TypeTrue
Convection FunctionsBake, Broil, Roast
Door RemovableYes
Hidden Bake ElementYes
Interior ColorGrey
Number Of Oven Lights1
Number Of Oven Racks3
Number Of Rack Guides7
Oven Cleaning TypeAquaLift® Self Clean
Oven Light Switch LocationOven Control
Oven Light TypeIncandescent
Oven Rack Type2 Standard and 1 Max Capacity
Bake Element Power18,000 BTU
Broiler Element Power11,000 BTU
Cooktop Details
Auto Re-ignitionNo
Cooktop Control LocationFront
Cooktop Surface ColorBlack on Stainless
Cooktop Surface MaterialPorcelain Coated Steel
Heating Element On Indicator LightNo
Hot Surface Indicator LightNo
Ignition TypeElectronic
Element/burner Details
Center Rear Element-burner TypeOval Burner
Cooktop Element StyleSealed Burner
Left Front Element-burner TypeHigh Output
Left Rear Element-burner TypeMulti Purpose
Number Of Cooking Element-burners5
Number Of Grates2
Right Front Element-burner TypeHigh Output
Right Rear Element-burner TypeSimmer
Center Rear Element-burner Power8,000 BTU
Left Front Element-burner Power17,000 BTU
Left Rear Element-burner Power9,500 BTU
Right Front Element-burner Power15,000 BTU
Right Rear Element-burner Power5,000 BTU
Grate Details
Grate DetailsCast Iron Grates, Continuous with Hinge, Dishwasher Safe, Matte Finish
Number Of Grates2
Details
Fuel TypeGas
LP ConvertibleYes - Kit Included
Oven Automatic Shut-offNo
Oven ConfigurationSingle Oven
Oven SelectionsControl Lock, Cook Time Indicator, Delay Start, Energy Save Mode, Frozen Bake, Keep Warm Setting, Rapid Preheat, Sabbath Mode
Power On Indicator LightNo
Power Outage CompatibleYes - Cooktop Only
Range ConfigurationFreestanding
Range TypeFreestanding
Controls
Display ColorBlue
Electronic Display TypeVFD
Electrical
Amps15
Power Cord IncludedYes
Volts120
Hz60
Refinements
FeaturesFrozen Bake™ Technology, EZ-2-Lift™ Hinged Grates, Self-Cleaning, True Convection, Bladed Knob, Whirlpool Handle
Features
Range FeaturesBladed Knob, EZ-2-Lift™ Hinged Grates, Frozen Bake™ Technology, Self-Cleaning, True Convection, Whirlpool Handle
Certifications
ADA CompliantNo
