| Brand | ZLINE |
| Model # | 697I30436 |
| Width | 36 Inch |
| Height | 12.5 Inch |
| Depth | 28 Inch |
$1,402.49
$1,499.95Save $97.46 (6%)
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width36 Inch
Height12.5 Inch
Weight60 lbs
Depth28 Inch
Dimensionsin. W x 28 in. D x 12.5 in. H
Chimney Dimensions20.75 in. W x 12 in. D x 16 H (x2) (Telescoping)
Warranty
Parts3 Year
Other
Noise Level30/41/49/52 (Decibles)
697i-3636" W x 27.5" D x 15" H
697i-4242" W x 27.5" D x 15" H
BrandZLINE Kitchen and Bath
697i-4848" W x 27.5" D x 15" H
697i-5454" W x 27.5" D x 15" H
697i-6060" W x 27.5" D x 15" H
Venting Size8" Outlet (Transition piece with backdraft damper to round ducting included)
Material21g #430 Stainless Steel
Lighting4 Directional LED Lights (3-Watt)
Speeds4 Speeds
Details
Appliance CategoryIsland RH
Color/ Finish FamilyBrushed 304 Stainless Steel
Airflow (q/l/m/h)280/420/560/700
MotorHigh Performance 700 CFM/4-Speed Motor
FiltersStainless Steel Baffle Filters (Dishwasher-safe)
Mount TypeWall Mount
Number Of Lights2
Number Of Speeds4
Control TypeSpeed/Timer Panel with LCD (3 Minute AutoTimer with Delayed Shutoff)
Button PanelPush Button Control Panel (4-Speed Fan Control/Lights/3 Minute AutoTimer with Delayed Shutoff)
Decibels30/41/49/52
Duct Size8
Voltage110
Amps5
Warranties & Certifications
Certifications And ListingsETL Listed
Manufacturer Warranty3 year parts, life-time motor warranty
