| Brand | Amana |
| Model # | AGR6603SMS |
| Width | 29.88 in. |
| Height | 46.25 in. |
| Depth | 27-1/5 in |
$678.00
$832.00Save $154.00 (19%)
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width29.88 in.
Height46.25 in.
Length27.2 in.
Weight163 lbs.
Cutout Depth (in)24
Cutout Height (in)36
Cutout Width (in)30 1/8
Depth Closed Excluding Handles22.9
Depth Closed Including Handles25 1/25
Depth With Door Open 90 Degree45.78
Gross Weight179
Net Weight163.0
Cutout Depth(in,inches)24.0000
Cutout Height(in,inches)36.0000
Cutout Width(in,inches)30.1250
Depth Closed Excluding Handles(in,inches)22.9000
Depth Closed Including Handles(in,inches)25.5500
Depth With Door Open 90 Degree(in,inches)45.7800
Maximum Height(in,inches)37.0000
Minimum Height(in,inches)36.0000
Cutout Height Min(in,inches)36.0000
Capacity5 cu. ft.
Common Size30 in
Cutout Depth24 in
Cutout Height36 in
Cutout Width30-1/8 in
Depth27-1/5 in
Maximum Height37 in
Minimum Height36 in
Oven Interior Depth19 in
Oven Interior Height18-3/8 in
Oven Interior Width25 in
Controls
Display ColorGreen
Electronic Display TypeLED
Cooktop Details
Auto Re-ignitionNo
Cooktop Control Knob ColorBlack
Cooktop Control Knob TypePlastic
Cooktop Control LocationFront
Cooktop Control TypeKnobs
Cooktop Surface ColorBlack
Ignition TypeElectronic
Cooktop Surface MaterialPorcelain Coated Steel
Heating Element On Indicator LightNo
Hot Surface Indicator LightNo
Certifications
ADA CompliantNo
UlYes
Prop 65Yes
Other
Capacity (cu Ft)5.00
Details
Cooktop ConfigurationAll Burners
Fuel TypeGas
LP ConvertibleYes - Kit Included
Power Outage CompatibleYes
Range TypeFreestanding
Natural Gas ConvertibleYes
Oven SelectionsAudible Signal, Bake, Bake Assist Temps, Broil, Cancel/Off, Clock, Control Lock, Keep Warm/Warm Hold, Sabbath Mode, Timer
Element/burner Details
Cooktop Element StyleSealed Burner
Left Front Element-burner TypeStandard
Left Rear Element-burner TypeStandard
Number Of Cooking Element-burners4
Right Front Element-burner TypeStandard
Right Rear Element-burner TypeStandard
Left Front Element-burner Power11,500 BTU
Left Rear Element-burner Power9,500 BTU
Number Of Grates2
Right Front Element-burner Power9,500 BTU
Right Rear Element-burner Power5,000 BTU
Exterior Details
Door TypeGlass
Oven Control Knob TypePlastic
Oven Control LocationBackguard
Oven Control TypeElectronic Touch
Oven Window SizeExtra Large
Handle ColorBlack
Handle MaterialPlastic
Handle TypeReach Through Handle
Oven Control Knob ColorBlack
Grate Details
Number Of Grates2
Grate DetailsDishwasher Safe, Flower Wire, Gloss Finish, Wire Grates
Smart Compatibility
ConnectivityNo
Oven Cavity Details
Automatic Convection Conversion Temperature AdjustNo
Bake Element Power16,500 BTU
Broiler Element Power16,500 BTU
Broiler LocationTop of Oven
Door RemovableYes
Hidden Bake ElementYes
Interior ColorGrey
Natural Gas ConvertibleYes
Number Of Oven Lights1
Number Of Oven Racks2
Number Of Rack Guides5
Oven Cleaning TypeSelf-Cleaning
Oven Cooking SystemThermal
Oven Light Switch LocationOven Control
Oven Light TypeIncandescent
Oven Rack TypeStandard (Both)
