| Brand | GE |
| Model # | JM250DTBB |
| Width | 27.13 in. |
| Height | 28.44 in. |
| Depth | 27.19 in. |
$1,949.00
$2,049.00Save $100.00 (5%)
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Overall Width27.125 in
Overall Height28.4375 in
Overall Depth27.1875 in
Net Weight104 lb
Depth Without Handle24.1875 in
Oven Interior Dimensions (w X H X D) (in.)19 x 15 x 18
Cooktop Width27.125 in
Depth With Door Open44.1875 in
Cabinet Opening27 in
Cabinet Width27 in
Width27.13 in.
Height28.44 in.
Length27.19 in.
Weight104 lbs.
Warranty
Parts1 Year
Labor1 Year
Labor WarrantyLimited 1-year entire appliance
Parts WarrantyLimited 1-year entire appliance
Warranty NotesSee written warranty for full details
Power & Ratings
Kw Rating At 240v10.6
Bake Wattage2000W
Electrical Requirements208/240V ; 60Hz ; 40A
Amp Rating At 208v40
Broiler Wattage3400W
Kw Rating At 208v8.0
Amp Rating At 240v40
Hertz60
Features
Element - Right Front6" 1250W 4-turn
Oven Features4-Pass Bake Element
Removable One-piece Drip BowlsChrome
Interior Oven Light1 Incandescent
Fuel TypeElectric
Oven InteriorGray
Oven Control FeaturesDelay Bake Option (Time Bake)
Cooktop Burner TypeCoil
Oven Rack Features2 Oven Racks
Element - Left Front8" 2400W 5-turn
Oven Cleaning TypeSelf-Clean
Product TypeDrop-In
Heating Element "on" Indicator LightYes
Cooktop TypeCoil
Element - Left Rear6" 1250W 4-turn
Element - Right Rear6" 1250W 4-turn
Cooktop SurfaceLift-Up Overhanging Cooktop Porcelain Enamel
Control LocationFront
Oven Rack Positions (single Or Upper/lower)4
Control TypeElectronic
Self-clean Oven Door LockAutomatic
Cooking TechnologyTraditional
Appearance
Oven Door FeaturesBig View Oven Window
HandleDesigner Style
InstallationFlush Appearance
Control KnobsColor-Matched
Handle DesignD-shaped
Handle ColorBlack
Color AppearanceBlack
