| Brand | Amana |
| Model # | AFCS2530TB |
| Height | 46.875 in |
| Depth | 27.75 in |
$528.00
$588.00Save $60.00 (10%)
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Capacity4.8 cu. ft.
Common Size30 in
Cutout Depth24 in
Cutout Height36 in
Cutout Width30 in
Depth27.75 in
Depth Closed Excluding Handles25.313 in
Depth Closed Including Handles27.75 in
Depth With Door Open 90 Degree46.688 in
Gross Weight142 lbs
Height46.875 in
Maximum Height47.875 in
Minimum Height46.875 in
Net Weight125 lbs
Oven Interior Depth18.5 in
Oven Interior Height18.125 in
Oven Interior Width24.5 in
Certifications
UlYes
Cooktop Details
Cooktop Control Knob TypeDishwasher Safe Plastic
Cooktop Control LocationBackguard
Cooktop Control TypeKnobs
Cooktop Surface MaterialPorcelain Coated Steel
Griddle IncludedNo
Heating Element On Indicator LightYes
Hot Surface Indicator LightNo
Cooktop Control Knob ColorBlack
Cooktop Surface ColorBlack
Details
Cooktop ConfigurationAll Burners
Fuel TypeElectric
LP ConvertibleNo
Oven Automatic Shut-offNo
Power On Indicator LightYes
Power Outage CompatibleNo
Range TypeFreestanding
Fingerprint ResistantNo
Natural Gas ConvertibleNo
Oven SelectionsBake, Broil, Keep Warm/Warm Hold
Electrical
Power Cord IncludedNo
Amps40
Hz60
Volts208
Element/burner Details
Cooktop Element StyleCoil
Left Front Element-burner Size8in.
Left Front Element-burner TypeStandard
Left Rear Element-burner Size6in.
Left Rear Element-burner TypeStandard
Number Of Cooking Element-burners4
Right Front Element-burner Power1250W
Right Front Element-burner Size6in.
Right Front Element-burner TypeStandard
Right Rear Element-burner Size8in.
Right Rear Element-burner TypeStandard
Left Front Element-burner Power2,100W
Left Rear Element-burner Power1,250W
Right Rear Element-burner Power2,100W
Exterior Details
Door TypeMetal & Glass
Oven Control Knob TypeDishwasher-Safe Plastic
Oven Control LocationBackguard
Oven Control TypeKnobs
Handle ColorBlack
Handle MaterialPlastic
Handle TypeReach Through Handle
Knob ColorBlack
Knob TypeDishwasher-Safe Plastic
Oven Control Knob ColorBlack
Oven Cavity Details
Automatic Convection Conversion Temperature AdjustNo
Bake Element Power2,400 W
Broiler Element Power3,400 W
Broiler LocationTop of Oven
Door RemovableYes
Hidden Bake ElementNo
Interior ColorGrey
Number Of Oven Racks2
Number Of Rack Guides5
Oven Cleaning TypeManual Clean
Oven Cooking SystemThermal
Oven Rack Type2 Standard
