| Brand | Fisher Paykel |
| Model # | RHV3484L |
| Width | 47 in. |
| Height | 35 in. |
| Depth | 29 in. |
$0.00
Ships When Available— Backorder OK
Rebate Available
Mail-in rebate savings
Fisher And Paykel 15% And Warranty Extension Rebate
Tiered- •Purchase any package of qualifying appliances valued at $25,000+ 15% Rebate + 5 year warranty
ManufacturerMail-InJan 1 – Dec 31, 2026
Open form to see all rebate tiersRebates applied via mail-in forms. Call (732) 426-0990 with questions.
This item is on backorder and will ship when available.
Lowest Price Guarantee
Need help? (732) 426-0990
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width47 in.
Height35 in.
Length29 in.
Warranty
Parts2 Year
Labor2 Year
GeneralYes
Parts And LaborLimited 2 years
Accessories (included)
GeneralYes
Adjustable Feet CoversYes
Branded Coin End CapYes
Burner Ratings
GeneralYes
Maximum Burner Power23500 BTU
Power Back Left18500BTU
Power Back Right18500BTU
Power Front Left23500BTU
Power Front Right18500BTU
Total Cooktop Power79000 BTU
Capacity
GeneralYes
Shelf Positions (main Oven)5
Shelf Positions (second Oven)5
Total Capacity (main Oven)4.8cu ft
Total Capacity Second Oven2.1cu ft
Usable Capacity (main Oven)3.8cu ft
Cleaning
GeneralYes
Easy Clean Porcelain BasepanYes
Pyrolytic Self-cleanYes
Controls
GeneralYes
Dial With Illuminated HaloYes
Dual Control Oven DialsYes
Electric Circuit4 wire
High Resolution DisplayYes
Metal Illuminated DialsYes
Multi-language InterfaceYes
Precise Cooking With Food ProbeYes
Recipe And Food Based FunctionsYes
Sabbath ModeYes
Smart ApplianceYes
Tilting Touch Screen InterfaceYes
Gas Requirements
GeneralYes
Fitting And Pipe½ NPT, min. â…" ∅ flex line
Supply Pressure (natural Gas)6" to 9" W.C
Oven Features
GeneralYes
Auto Re-ignition SystemYes
Concealed ElementYes
Electronic Oven ControlYes
Full Extension Telescopic Sliding ShelvesYes
Internal LightYes
True ConvectionYes
Oven Functions
GeneralYes
Air FryYes
BakeYes
Classic BakeYes
CleanYes
Convection BakeYes
Convection BroilYes
DehydrateYes
Maxi BroilYes
Number Of Functions15
Pastry BakeYes
Pizza BakeYes
Rapid ProofYes
RoastYes
Slow CookYes
True ConvectionYes
WarmYes
Oven Performance
GeneralYes
Bake4600W
Broil3600W
Broil Power4000W
Main Oven - True Convection Power2500W
Power Requirements
GeneralYes
Connection4-prong grounding type [NEMA 14-50P plug]
Power Supply120 / 240 V, 60 Hz
Service50 A
Rangetop Features
GeneralYes
Gentle HeatYes
Heat Settings9
Induction Cooking TechnologyYes
Sealed Range TopYes
Smartzone2
Vent Trim IncludedYes
Zone BridgingYes
Rangetop Performance
GeneralYes
Left Front Zone Rating2100 (3700)W
Left Rear Zone Rating2100 (3700)W
Number Of Burners4
Number Of Cooking Zones4
PowerboostYes
Powerboost All Zonesup to 3700W
Right Front Zone Rating2100 (3700)W
Right Rear Zone Rating2100 (3700)W
Recommended Back Guards Ventilation
GeneralYes
Combustible SituationBGRV3-3048H
Non Combustible SituationBGRV2-3048 / BGRV2-1248
Recommended HoodHCB48-12_N (48" Professional Range Hood, Dual Blower)
Safety
GeneralYes
ADA CompliantYes
Pan Detection SystemYes
Safety Time OutYes
Surface Hot IndicatorsYes
Secondary Oven Features
GeneralYes
3/4 Extension Racks2
Electronic Oven ControlYes
Food ProbeYes
Internal LightYes
Secondary Oven Functions
GeneralYes
Air FryYes
BakeYes
Classic BakeYes
Convection BakeYes
Convection BroilYes
Maxi BroilYes
Number Of Secondary Oven Functions11
Pastry BakeYes
Pizza BakeYes
Rapid ProofYes
RoastYes
WarmYes
