| Brand | Fisher Paykel |
| Model # | RDV3486GDL |
| Width | 47 in. |
| Height | 35 in. |
| Depth | 29 in. |
$0.00
Ships When Available— Backorder OK
Rebate Available
Mail-in rebate savings
Fisher And Paykel 15% And Warranty Extension Rebate
TieredUP TO 15% REBATE & WARRANTY EXTENSION
ManufacturerMail-InJan 1 – Dec 31, 2026
Open form to see all rebate tiersRebates applied via mail-in forms. Call (732) 426-0990 with questions.
This item is on backorder and will ship when available.
Lowest Price Guarantee
Need help? (732) 426-0990
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width47 in.
Height35 in.
Length29 in.
Warranty
Parts2 Year
Labor2 Year
GeneralYes
Parts And LaborLimited 2 years
Accessories (included)
GeneralYes
Adjustable Feet CoversYes
Branded Coin End CapYes
Telescopic Sliding RunnersYes
Burner Ratings
GeneralYes
Maximum Burner Power19000 BTU
Power Back Centre13000BTU
Power Back Left13000BTU
Power Back Right13000BTU
Power Front Centre15000BTU
Power Front Left19000BTU
Power Front Right15000BTU
Power Griddle15000BTU
Total Cooktop Power103000 BTU
Capacity
GeneralYes
Shelf Positions (main Oven)5
Shelf Positions (second Oven)5
Total Capacity (main Oven)4.8cu ft
Total Capacity Second Oven2.1cu ft
Usable Capacity (main Oven)3.8cu ft
Cleaning
GeneralYes
Easy Clean Porcelain BasepanYes
Pyrolytic Proof Shelf RunnersYes
Controls
GeneralYes
Dial With Illuminated HaloYes
Dual Control Oven DialsYes
High Resolution DisplayYes
Multi-language InterfaceYes
Precise Cooking With Food ProbeYes
Recipe And Food Based FunctionsYes
Sabbath ModeYes
Smart ApplianceYes
Tilting Touch Screen InterfaceYes
Wi-Fi ConnectivityYes
Gas Requirements
GeneralYes
Fitting And Pipe½ NPT, min. ⅝" ∅ flex line
Supply Pressure (lpg)11" to 14" W.C
Oven Features
GeneralYes
Auto Re-ignition SystemYes
Concealed ElementYes
Electronic Oven ControlYes
Food ProbeYes
Full Extension Telescopic Sliding ShelvesYes
Large Broil PanYes
Self-clean Proof Side RacksYes
True ConvectionYes
Oven Functions
GeneralYes
Air FryYes
BakeYes
BroilYes
Classic BakeYes
CleanYes
Convection BakeYes
Convection BroilYes
Maxi BroilYes
Number Of Functions15
Pastry BakeYes
Pizza BakeYes
Rapid ProofYes
RoastYes
Slow CookYes
True ConvectionYes
WarmYes
Power Requirements
GeneralYes
Connection4-prong grounding type [NEMA 14-50P plug]
Power Supply120 / 240 V, 60 Hz
Service50 A
Rangetop Features
GeneralYes
Sealed Range TopYes
Vent Trim IncludedYes
Recommended Back Guards Ventilation
GeneralYes
Combustible SituationBGRV3-3048H
Non Combustible SituationBGRV2-3048 / BGRV2-1248
Recommended HoodHCB48-12_N (48" Professional Range Hood, Dual Blower)
Safety
GeneralYes
ADA CompliantYes
Child LockYes
Secondary Oven Features
GeneralYes
3/4 Extension Racks2
Concealed ElementYes
Electronic Oven ControlYes
Food ProbeYes
Internal LightYes
Secondary Oven Functions
GeneralYes
Air FryYes
BakeYes
Classic BakeYes
Convection BakeYes
Convection BroilYes
Maxi BroilYes
Number Of Secondary Oven Functions11
Pastry BakeYes
Pizza BakeYes
Rapid ProofYes
RoastYes
WarmYes
