| Brand | Fisher Paykel |
| Model # | RGV3486GDL |
| Width | 47 in. |
| Height | 35 in. |
| Depth | 29 in. |
$0.00
Ships When Available— Backorder OK
Rebate Available
Mail-in rebate savings
Fisher And Paykel 15% And Warranty Extension Rebate
TieredUP TO 15% REBATE & WARRANTY EXTENSION
ManufacturerMail-InJan 1 – Dec 31, 2026
Open form to see all rebate tiersRebates applied via mail-in forms. Call (732) 426-0990 with questions.
This item is on backorder and will ship when available.
Lowest Price Guarantee
Need help? (732) 426-0990
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Width47 in.
Height35 in.
Length29 in.
Burner Ratings
GeneralYes
Maximum Burner Power17000 BTU
Power Back Centre13000BTU
Power Back Left13000BTU
Power Back Right13000BTU
Power Front Centre15000BTU
Power Front Left17000BTU
Power Front Right15000BTU
Power Griddle15000BTU
Total Cooktop Power101000 BTU
Capacity
GeneralYes
Shelf Positions (main Oven)5
Total Capacity (main Oven)5.3cu ft
Total Capacity Second Oven2.4cu ft
Usable Capacity (main Oven)3.9cu ft
Cleaning
GeneralYes
Easy Clean Porcelain BasepanYes
Controls
GeneralYes
Metal Illuminated DialsYes
Gas Requirements
GeneralYes
Fitting And Pipe½ NPT, min. ⅝" ∅ flex line
Supply Pressure (lpg)11" to 14" W.C
Oven Features
GeneralYes
Auto Re-ignition SystemYes
Broil PanYes
Electronic Oven ControlYes
Full Extension Telescopic Sliding ShelvesYes
Infrared BroilerYes
Oven Functions
GeneralYes
BakeYes
BroilYes
Convection BakeYes
Number Of Functions4
Slow CookYes
Oven Performance
GeneralYes
Bake16500 BTU
Power Requirements
GeneralYes
Connection3-prong grounding type plug
Power Supply120 V, 60 Hz
Service15 A
Rangetop Features
GeneralYes
Sealed Range TopYes
Recommended Back Guards Ventilation
GeneralYes
Combustible SituationBGRV3-3048H
Non Combustible SituationBGRV2-3048 / BGRV2-1248
Recommended HoodHCB48-12_N (48" Professional Range Hood, Dual Blower)
Safety
GeneralYes
ADA CompliantYes
Secondary Oven Features
GeneralYes
3/4 Extension Racks2
Electronic Oven ControlYes
Internal LightYes
Secondary Oven Functions
GeneralYes
BakeYes
Number Of Secondary Oven Functions4
ProofYes
Slow CookYes
Warranty
GeneralYes
Parts And LaborLimited 2 years
