| Brand | GE |
| Model # | JD630DTBB |
| Width | 31.25 in. |
| Height | 27 in. |
| Depth | 28.5 in. |
$1,999.00
$2,099.00Save $100.00 (5%)
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Net Weight152 lb
Depth Without Handle25.75 in
Oven Interior Dimensions (w X H X D) (in.)24 x 17-1/2 x 18-1/4
Cooktop Width31.25 in
Depth With Door Open44.625 in
Cabinet Opening30 in
Overall Width31.25 in
Overall Depth28.5 in
Overall Height27 in
Cabinet Width30 in
Width31.25 in.
Height27 in.
Length28.5 in.
Weight152 lbs.
Warranty
Parts1 Year
Labor1 Year
Labor WarrantyLimited 1-year entire appliance
Parts WarrantyLimited 1-year entire appliance
Warranty NotesSee written warranty for full details
Power & Ratings
Kw Rating At 240v11.9
Bake Wattage3410W
Electrical Requirements208/240V ; 60Hz ; 40A
Amp Rating At 208v40
Broiler Wattage3420W
Kw Rating At 208v8.9
Amp Rating At 240v40
Hertz60
Features
Element - Right Front9"/6" 3000W Power Boil
Oven Features6-Pass Bake Element
Interior Oven Light1 Incandescent
Fuel TypeElectric
Melt SettingYes
Ou CertifiedNo
Oven Control FeaturesDelay Bake Option With Cook & Hold
Cooktop Burner TypeRadiant
Oven Rack Features2 Oven Racks
Power Boil BurnerYes
Element - Left Front8" 2000W
Oven Cleaning TypeSelf-Clean
Hot Surface Indicator Lights4
Product TypeDrop-In
Heating Element "on" Indicator Light2
Cooktop TypeRadiant Smoothtop
Element - Left Rear8" 2000W
Sabbath ModeYes
Element - Right Rear6" 1200W
Cooktop SurfaceBlack Ceramic Glass
Control LocationFront
Oven Rack Positions (single Or Upper/lower)7
Control TypeElectronic
Self-clean Oven Door LockAutomatic
Cooking TechnologyTraditional
Appearance
Oven Door FeaturesBig View Oven Window
HandleDesigner Style
InstallationFlush Appearance
Control KnobsBlack
Handle ColorBlack
Color AppearanceBlack on Black
