| Brand | GE |
| Model # | GE20L08BAR |
| Width | 19.25 in. |
| Height | 25.75 in. |
| Depth | 19.25 in. |
$399.00
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Lowest Price Guarantee
Need help? (732) 426-0990
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Overall Width19.25 in
Overall Height25.75 in
Product Height (to Top Of Unit)25.75 in
Overall Depth19.25 in
Net Weight54.2 lb
Connection Sizes - Water Inlet (mnpt)3/4"
Connection Sizes - Hot Water Outlet (mnpt)3/4"
Product Diameter19 1/4 in
Product Height (to Top Of Water Inlet/outlet Connections)8.875/17.125 in
Width19.25 in.
Height25.75 in.
Length19.25 in.
Weight54.2 lbs.
Features
Control TypeThermostat
ControlsMechanical Temperature Control
Max. Operating Pressure (psi)150
Temp & Pressure Relief ValveYes
Height DescriptionLow Boy with Side Port
Heating ElementStainless steel
Max: Operating Pressure (psi)150
Fuel TypeElectric
ConfigurationLowboy
Installation LocationIndoor
Operating ModesStandard Electric
Rated Storage Capacity18
Drain Valve TypePlastic
Gph Recovery @ 90 Degrees F25.1
Mobile Home CompatibleNo
Temperature Setting Factory Default120° F
Product TypeElectric Thermostat
Family Size1-2 People
Water Connection LocationSide
Foam InsulationYes
Point Of UseNo
Anode RodAluminum
Temperature Setting90-150° F Range
Rated Capacity18.0 gal
Power & Ratings
Heating - Electric - Heater Watts3800
Electrical ConnectionDirect-Wire
Operating Water Pressure20-125 PSI
Volts/hertz240V; 60Hz
Voltage (max)240 V
Electrical Circuit Required208V/240V 60 Hz Dedicated 30 Amp Min.
Warranty
Warranty NotesSee written warranty for full details
Parts8 Year
Labor1 Year
Parts WarrantyLimited 8-year tank and parts
Labor WarrantyLimited 1-year entire appliance
Capacity
Unit Capacity18 Gallons
Appearance
Color AppearanceGray
