| Brand | GE |
| Model # | GE10P08BAR |
| Width | 14.8 in. |
| Height | 24.5 in. |
| Depth | 14.75 in. |
$329.00
Ships When Available— Backorder OK
This item is on backorder and will ship when available.
Lowest Price Guarantee
Need help? (732) 426-0990
Stack & Save
Save up to $1,000 on qualifying orders
Dimensions
Overall Width14.8 in
Overall Height24.5 in
Product Height (to Top Of Unit)24.5 in
Overall Depth14.75 in
Net Weight40.9 lb
Connection Sizes - Water Inlet (mnpt)3/4"
Connection Sizes - Hot Water Outlet (mnpt)3/4"
Product Diameter14.800 in
Width14.8 in.
Height24.5 in.
Length14.75 in.
Weight40.9 lbs.
Features
Power Cord Length6' Included
ControlsMechanical Temperature Control
Max. Operating Pressure (psi)150
Temp & Pressure Relief ValveTop
Height DescriptionPoint of Use
Heating ElementStainless steel
Max: Operating Pressure (psi)150
Fuel TypeElectric
ConfigurationSpace Saver
Installation LocationIndoor
Drain Valve TypePlastic
Temperature Setting Factory Default120° F
Product TypeElectric Point Of Use
Water Connection LocationSide
Point Of UseYes
Anode RodAluminum
Temperature Setting70-140° F Range
Rated Capacity10.0 gal
Appearance
InstallationFree-Standing
Color AppearanceGray
Power & Ratings
Power Rating-kw1.5
Amps12
Hertz60
Voltage (max)120 V
Warranty
Warranty NotesSee written warranty for full details
Parts WarrantyLimited 8-year tank and parts
Labor WarrantyLimited 1-year entire appliance
Capacity
Unit Capacity10 Gallons
